Name/Title
Drawings, ArchitecturalEntry/Object ID
2024.1.58Description
Architectural drawings and specifications by C. Howard Kable and Joseph W. Heiler related to the property at 2515 NW Overton St., Portland, Oregon. Projects for Mr. Henry Engel.
REFERENCE SPECIFICATIONS (Joseph W. Heiler and H.A. Angell) FOR 1311 NW 25th AVE, 1940:
A - (No Sheet #) - Specifications - Duplex for Mr. Henry Engel, NW Cor. NW 25th & Overton, Portland, Ore. - Set No. 2 (Joseph W. Heiler Architect, H.A. Angell, Assoc. Architect) (07/03/40)
B - (No Sheet #) - Specifications - Duplex for Mr. Henry Engel, NW Cor. NW 25th & Overton, Portland, Ore. - Set No. 5 (Joseph W. Heiler Architect, H.A. Angell, Assoc. Architect) (07/03/40)
DUPLEX - 2515 NW OVERTON ST. (C. Howard Kable and Joseph W. Heiler) (apparently unbuilt), 1948:
C - Sheet 1 - DUPLEX - Plot Plan, Basement Floor Plan (06/01/48)
D - Sheet 2 - DUPLEX - 1st Floor Plan, Schedule (06/01/48)
E - Sheet 3 - DUPLEX - Elevations, Sections (06/01/48)
F - Sheet 4 - DUPLEX - Interior elevations (06/01/48, rev. 06/18/48)
RESIDENCE - 2515 NW OVERTON ST. (C. Howard Kable), 1950:
G - Sheet 1 - RESIDENCE - Plot Plan, Basement Floor Plan, Details of Garage (06/20/50)
H - Sheet 2 - Fireplace Elevations, Roof Plan, Floor Plan, Schedules (06/20/50)
I - Sheet 3 - Elevations, Section (06/20/50)
J - Sheet 4 - Kitchen Details (06/20/50)
Engel appears to have built a duplex, 1311 NW 25th Ave, in 1940, designed by Joseph W. Heiler and H.A. Angell. In 1948, Joseph W. Heiler and C. Howard Kable designed a duplex to sit on the adjacent parcel, now 2515 NW Overton St. The duplex was apparently never built, and in 1950, Kable designed a single family residence for the 2515 NW Overton address, extant as of 10/1/2026.Lexicon
Search Terms
C. Howard Kable, Joseph W. Heiler, H.A. Angell, 2515 NW Overton St., 1311 NW 25th Ave., Northwest Portland
