Isometric ellipse drafting template (Helix H82)

Object/Artifact

-

Archive of Cuban Socialism

Name/Title

Isometric ellipse drafting template (Helix H82)

Entry/Object ID

2025.16.5

Description

Rectangular translucent plastic drafting stencil with cut-out ellipses for drawing in isometric projection. Twenty-six bevelled-edge elliptical apertures are arranged in three registers, each labeled with its major-axis dimension in millimeters; the upper long edge carries a graduated ruler scale. Surface is discolored with amber-brown staining and scattered scuffs but structurally intact. Approx. 200 × 118–125 mm per manufacturer specification (not independently measured).

Collection

Evelyn Sosa collection

Acquisition

Accession

2025.16

Source or Donor

Evelyn Sosa

Acquisition Method

Gift

Made/Created

Manufacturer

Helix

Place

Country

U.K.

Continent

Europe

Notes

Date: Undated. Cannot be confirmed within 1959–1990 and may fall outside it; the H82 model has remained in catalog for decades.

Inscription/Signature/Marks

Notes

"HELIX H82 / Made in England" (lower right) "35° 16′ ISOMETRIC / ELLIPSE TEMPLATE" (lower center) "METRIC" (lower left, molded relief) Edge ruler graduated 0–190 mm Aperture size labels: upper row 50, 45, 40, 35, 32; middle row 15, 16, 18, 20, 22, 25, 28, 30; lower row 14, 13, 12, 11, 10, 9, 8, 7, 6, 5, 4, 3, 2 (26 ellipses, 2–50 mm — matches manufacturer's published specification)
