Tool, Block and Tackle

Object/Artifact

Bytown Museum / Musée Bytown

Name/Title

Tool, Block and Tackle

Entry/Object ID

I298 a,b

Description

[a]: Two wide-grooved iron pulleys within a wooden frame. The frame is made of three oval shaped pieces of light colored wood screwed together to form two compartments for the pulleys; passing through holes in center of the frame sides is a bolt on which both pulleys revolve. A strap of iron protrudes through top of frame in a loop, and it's overlapped by another arching strap of iron. It's through these straps that the eye of the hook is linked. The hook is rounded in cross-section, "j-shaped" and turns outward slightly at the tapered point. The eye is angled obliquely from hook. [b]: One doubled piece of rope hangs down from pulleys.

Lexicon

Nomenclature 4.0

Nomenclature Tertiary Object Term

Block and Tackle

Nomenclature Secondary Object Term

Hoist

Nomenclature Primary Object Term

Apparatus, Hoisting

Nomenclature Sub-Class

Mechanical Devices

Nomenclature Class

Mechanical T&E

Nomenclature Category

Category 05: Tools & Equipment for Science & Technology

Search Terms

LIFTING DEVICE, LIFTING DEVICE, Science & Technology T&E

Legacy Lexicon

Object Name

Tool, Block and Tackle, Apparatus, Hoisting

Dimensions

Height

39 cm

Width

14 cm

Depth

14 cm

Dimension Notes

DIAMETER OF ROPE: 1.5CMHANGS 200CM FROM PULLEYS.

Material

Iron, Wood, Jute
