[Gauge] Wrights Canadian Rope Ltd., Sheave, Metal Silver

Object/Artifact

-

Canadian Energy Museum

Name/Title

[Gauge] Wrights Canadian Rope Ltd., Sheave, Metal Silver

Entry/Object ID

2023.18.8

Tags

Engineering, Gauge, Metal, Oil, Oil Field, Oil Industry, Oilfield, Sheave, Silver, Technical Equipment, Tool, Wire Rope, Wright Canadian Ropes Ltd.

Description

A metal sheave gauge, in a fanning configuration, and branded to Wright Canadian Ropes Ltd. Appearance: A sheave gauge made from metal (likely steel), with 7 tabs connected with a small domed metal bolt. The tabs transition in shape from narrow drop-shaped (narrow rounded at bold ent and more bulbous at alternate end), to a rounded drop shape. On the first tab (narrowest) is engraved the text "WRIGHTS CANADIAN ROPES LTD.". Each of the tabs also bears the corresponding measurements engraved, in inches. Included Measurements: 1 1/8" DIA+ 3/128 1 1/4" DIA+ 1/32 1 3/8" DIA+ 1/32 1 1/2" DIA+ 1/32 1 3/4" DIA+ 3/64 2" DIA+ 3/64 2 1/4" DIA+ 3/64

Collection

Michael Armstrong Collection

Cataloged By

Danielle P. Lane

Category

Technical and Equipment Ruler
Technical Stationery and Tools, Technical Equipment

Acquisition

Accession

2023.18

Source or Donor

Michael Armstrong

Acquisition Method

Gift

Lexicon

Nomenclature 4.0

Nomenclature Secondary Object Term

Gauge, Wire

Nomenclature Primary Object Term

Gauge, Metalworking

Nomenclature Class

Metalworking T&E

Nomenclature Category

Category 04: Tools & Equipment for Materials

Dimensions

Width

59 mm

Depth

9 mm

Length

83 mm

Materials

Material

Metal

Material Notes

Likely steel

Color

Silver

Condition

Reason for Exam

At Acquisition

Overall Condition

Good

Condition Detail

Scratch, Discoloration, Residue, Finger Prints / Marks, Dent

Date Examined

Jul 7, 2023

Examined By

Danielle P. Lane

Cleanliness

Some residue and fingerprint on the surface of the metal.

Surface

Light to moderate scratches throughout. Notable examples include straight scratches on the front of the largest three tabs. The finish/lamination has become separated and broken away on the back on the largest tab.

Materials

Deep dent in an arch around the bold on the back of the largest tab. Discolouration patches in the metal or finish, most so on the middle tab (front and back).

Mechanism

Structurally sound. Parts move easily with minimal force.
