[Joint Identifier] Drilco, inc. Ruler

Object/Artifact

-

Canadian Energy Museum

[Joint Identifier] Drilco, inc. Ruler - Side A: View of Side A
[Joint Identifier] Drilco, inc. Ruler - Side A

View of Side A

Name/Title

[Joint Identifier] Drilco, inc. Ruler

Entry/Object ID

2003.41.7

Tags

Ruler, Tool, Drilco, Technical Equipment, Metal, Joint Identifier

Description

A stainless steel ruler with cutouts to identify joints, in addition to an inch rule. Features: Double-sided ruler made of stainless steel, all features engraved. Side A has an inch rule along the top (0in-6in), and along the bottom is "BOX DIAMETER OF COUNTERBORE". To the left are the "4 THDS. PER IN.-60°" cutouts on the bottom edge. To the right side are the "5 THDS. PER IN.-60°" (top), and "3 1/2 THDS. PER IN.-90°" (bottom). Between these cutouts is also the text in green "DRILCO". There is a round cutout a little in from the right, where a depth gauge can be attached, though one is not included nor is there any sign one has been attached in the past. On Side B, the top edge bears the "PIN DIAMETER AT SHOULDER". Along the bottom is the text: "DRILCO JOINT IDENTIFIER; DRILCO; DIVISION SMOTH INTERNATIONAL, INC.; BOX 3135, MIDLAND, TEXAS". Between the left-side cutouts is also the text in green "DRILCO".

Collection

Harry Bagot Collection

Cataloged By

Danielle P. Lane

Category

Technical and Equipment Ruler
Technical Stationery and Tools, Technical Equipment

Acquisition

Accession

2003.41

Made/Created

Manufacturer

The Drill Collar Service Co. Inc.

Date made

circa 1951

Time Period

20th Century

Place

City

Midland, Texas

Country

United States of America

Lexicon

Nomenclature 4.0

Nomenclature Primary Object Term

Ruler

Nomenclature Class

Weights & Measures T&E

Nomenclature Category

Category 05: Tools & Equipment for Science & Technology

Nomenclature Category

Category 06: Tools & Equipment for Communication

Dimensions

Width

26 mm

Depth

1 mm

Length

181 mm

Material

Metal

Color

Silver, Green

Condition

Reason for Exam

Accession

Overall Condition

Good

Condition Detail

Scratch, Residue, Warping

Date Examined

Feb 17, 2023

Examined By

Danielle P. Lane

Cleanliness

Notable coloured residue, particularly on Side B. On Side A there is a green residue to the right-of-centre and brown residue to the left of it. On Side B, there is a large area of yellow-green residue, to the right is a dark patch of green residue, and to the right again is a larger light-green patch or residue. Above the round cutout are three spots of red-brown residue.

Surface

Thorough scuffs and light-medium scratches across all surfaces from use.

Structure

Slight bend in the middle of the ruler.
