[Deflecting Tool Setting Chart] Dowell Schlumberger, Sticker, Yellow, Pleather, Brown

Object/Artifact

-

Canadian Energy Museum

Name/Title

[Deflecting Tool Setting Chart] Dowell Schlumberger, Sticker, Yellow, Pleather, Brown

Entry/Object ID

2025.22.9

Tags

Measuring Tool, Dowell Schlumberger, Brown, Yellow, Tool, Eastman Oil Well Surveys

Description

A brown pleather pouch branded to Dowell Schlumberger containing a deflecting tool setting chart, branded to Eastman Oil Well Survey Company. The pouch is thin, with a single pocket. The front displays two stickers branded to Dowell Schlumberger. The top sticker is placed at the top of the pouch and is a small grey rectangle with a blue outline of a hexagon and blue text within it reading, "DOWELL SCHLUMBERGER". The second sticker is placed right underneath and is much larger. It is the shape of a hexagon with a yellow background and blue text. The deflecting tool setting chart is medium-sized, easy to hold, and has one side with measurements. Black text on the right front reads, "EASTMAN OIL WELL SURVEY COMPANY HOUSTON-DENVER-LONG BEACH "OUIJA"". It's made of clear plastic with a movable ruler on one side. Within the chart is a rectangular piece, made of a thick card material, white with black text, and displaying multiple measurement numbers. The back of the measurement paper displays black text, centre-aligned, reading, "EASTMAN OIL WELL SURVEY CO. DEFLECTING TOOL SETTING CHART "OUIJA"". At the bottom right corner, in small text, reads, "PRICE $5.00". On the left and right, on both sides, is a cut-out semicircle, where the user is able to grab onto the paper and move it around.

Collection

Hugo Leentvaar Collection

Cataloged By

Chloe Anna

Acquisition

Accession

2025.22

Source or Donor

Mike Mitchell, Hugo Leentvaar

Acquisition Method

Gift

Dimensions

Height

5 mm

Width

112 mm

Depth

263 mm
