Diagrams: D.L. & W. Railroad, Switching Locomotive type 4-0-4, 1933-1934.Entry/Object ID
2010.007.0086Scope and Content
Classification book sheets: The Delaware, Lackawanna & Western Railroad Company, Switching Locomotive type 4-0-4, 1933-1934. Blueprint (white on blue), 4-1/2" high x 10-3/4" wide. Two drawings.
Dimensioned side elevation and specification sheets for this diesel electric. Date drawings were made is not indicated, probably mid to late 1930s.While not so marked as M.P. & E. [Motive Power & Equipment] sheets, they conform in size to typical ones.
Sheet V-1, side elevation: The Delaware, Lackawanna & Western Railroad Company, class and tonnage rating not stated, Road Nos. 401-408, type 4-0-4.
Sheet V-2, specifications: The Delaware, Lackawanna & Western Railroad Company, Switching Locomotives, Road Nos. 401-408, type 4-0-4; builder A.L.Co. [ALCO, American Locomotive Works]; built 1933-1934.Acquisition
Accession
2010.007Source or Donor
Lukacs, ClaireAcquisition Method
GiftCredit Line
Museum Collections. Gift of a friend of the Museum.Archive Details
Date(s) of Creation
1934 - 1940Archive Notes
Date(s) Created: 1930s
Date(s): 1934-1940General Notes
Note
Notes: Taber lists all but no. 401 as built in 1934. No 408 is listed, but a 409 built in 1934 is listed. All but two were scrapped 1959-1961.
The Lackawanna Terminal in Hoboken was the main eastern terminus for the railroad's passenger service and certain freight operations. This switcher was used in Hoboken. It is unknown if the drawings were made in Hoboken or at one of the many other DL&W facilities, although the engineering department was at one time in Hoboken.
The sheets were a routine method for inventory of motive power and other stock.
