Exercise, School

Archive

-

Mississippi Valley Textile Museum

Name/Title

Exercise, School

Entry/Object ID

1991.05.03.05

Scope and Content

2 pages of peach coloured, legal sized paper. The Victoria University of Manchester College of Technology June Sessional Examinations 1939 Session 1938-39 Mechanics of Textile Machinery 8 Questions One diagram in question 2 on first page Revers; 2 Blank pages Transcription : 10.000. P.D.S. 7/M. THE VICTORIA UNIVERSITY OF MANCHESTER (FACULTY OF TECHNOLOGY) COLLEGE OF TECHNOLOGY JUNE SESSIONAL EXAMINATIONS, 1939 SESSION 1938-39 MECHANICS OF TEXTILE MACHINERY TEXTILE INDUSTRIES. 2nd Year Ordinary and 1st Year Higher Thursday, 22nd June, 1939. 9.30 a.m.- 12.30 p.m. Candidates are required to attempt not more than FIVE questions, at least TWO from each section. Questions: SECTION I 1. The following picker displacements, during successive 4 degree movements of the crankshaft, were found by turning a cone underpick loom slowly, by hand, during the picker acceleration period: Crankshaft displacement, degrees, (total) Picker displacement, Inches (Increments) Plot the picker velocity curve for a loom speed of 180 picks per minute, assuming the game relationship between picker and crank shaft displacements as given In the table. Explain, briefly, why this assumption Is not correct. Estimate the probable maximum shuttle speed and the work done per minute in accelerating the shuttle, if its weight is 0.75 lb. 2. Figure I shows a section through a porcelain eye, placed in the side of a shuttle. Define the angle at which the eye should be set, with relation to the centre line of the shuttle, so that the tension in the weft, due to friction at the eye, may be the same on both traverses of the shuttle. Ignore the thickness of the weft. FIGURE 1

Collection

Textile Industry

Cataloged By

Murray, Pam

Lexicon

Nomenclature 4.0

Nomenclature Primary Object Term

Exercise, School

Nomenclature Sub-Class

Instructional Documents

Nomenclature Class

Documentary Objects

Nomenclature Category

Category 08: Communication Objects

LOC Thesaurus for Graphic Materials

Education, Examinations, Tests, Textile industry

Search Terms

Manchester University

Location

Location

Drawer

D65

Room

Collections Room

Building

M.V.T.M.

Category

Permanent

Date

November 7, 2023

Location

Container

Archive Box 2

Shelf

Shelf 2, Shelf 2

Wall

Wheel Rack

Room

Collections Room

Building

M.V.T.M.

Category

Permanent

Moved By

Whit, Elizabeth

Date

July 7, 2016

Relationships

Related Person or Organization

Person or Organization

Bornet, George M.

General Notes

Note

Status: OK Status By: Cotter, Ellen Status Date: 2022-06-07
