Canadian National: Detailed Estimate of Retiring theWest Switch of 647 through Siding, Relocating 160’ of Track in Thorlake

Publication

-

Northern Ontario Railroad Museum and Heritage Centre

Name/Title

Canadian National: Detailed Estimate of Retiring theWest Switch of 647 through Siding, Relocating 160’ of Track in Thorlake

Entry/Object ID

2021.1018.01

Description

Detailed estimate for the retirement of west switch of 647 through siding and relocating 160' of track in Thorlake ON in 1963. The back page shows a plan/drawing of the Thorlake subdivision. The sheet covers the description, quantity, unit, unit price, and total cost for: Retirement at Estimated Original Cost: Rail 115#, 2.66, NT., $40.00, $106.00 Turnout #12, 115#, Ea., $772.80, $773.00 Insulated Joints, 4, joints, $19.68, $79.00 Splice Bars, 4, prs., $2.64, $11.00 Signal Material, sum, $200.00 Bolts (24) 115#, .56, cwt., $3.33, $8.00 Washers, 0.24, M, $51.25, $1.00 Spikes, 2.51, cwt., $3.33, $8.00 Switch Ties #12, 1, set., $186.89, $187.00 Tie Plates, 106, es., $0.29, $31.00 Flanger Signs, 2, ea., $1.60, $3.00 MSE 6%, $78.00 Labor Installation Turnout and Handling, sum, $326.00 Engineering 1%, $18.00 General Expneses 2.3%, $42.00 Salvage: Rail, 2.66, N.T., $45.00, $120.00 OTM, 5.8, N.T., $25.00, $145.00 Labor Removing and Loading Material, sum, $200 Relocating Track, 160, T.F., $2.57, $411.00 Track Ties Replacing Switch Ties: Ties #2 T.S.W. 87, ea., $2.95, $257.00 Labor Inntailing, 87, ea., $1.30, $113.00 Totals: $981, Investment account: $1496, Maintenance account: $611, Other accounts: $265 Distinguishing Features: none

Context

Original document. Canadian National was created following the end of the First World War, by combining five lines which were financially troubled. It soon became the largest railway in the country. Canadian National Railways was founded in 1919 as a combination of several railways that had become bankrupt and were being ran by the Canadian Government Railways, its primary service was freight but also operated passenger service until 1978 until it was absorbed by VIA rail. The Canadian National Railways was created by the Government of Canada as a means to fund the failing railway corporations including: Intercolonial Railway of Canada, National Transcontinental Railway, Prince Edward Island Railway, and Hudson's Bay Railway.

Collection

Library Archive

Category

Canadian National

Acquisition

Source (if not Accessioned)

unknown

Notes

Date Acquired: unknown Method of Acquisition: Donation (?)

Lexicon

Legacy Lexicon

Object Name

Detailed Estimate

Class

Financial Records

Category

Primary Source

Publication Details

Author

B.R. Trask

Place Published

District

District of Sudbury

State/Province

Ontario

Country

Canada

Continent

North America

Date Published

1963

ISBN

n/a

Notes

Materials: paper, ink

Inscription/Signature/Marks

Notes

"1 of 1, Canadian National Railway Company, Great Lakes Region, Northern Ontario, Ruel, Mile 36.1, Ontario, Retire West Switch of 647 through siding relocate 160' of track, Thorlake, RUE 52-5, 4 Oct, 1963, 69/63, Oct 4/63, B.R. Track R.B. Avery, Retirement at Estimated Original Cost: Rail 115#, 2.66, NT., $40.00, $106.00 Turnout #12, 115#, Ea., $772.80, $773.00 Insulated Joints, 4, joints, $19.68, $79.00 Splice Bars, 4, prs., $2.64, $11.00 Signal Material, sum, $200.00 Bolts (24) 115#, .56, cwt., $3.33, $8.00 Washers, 0.24, M, $51.25, $1.00 Spikes, 2.51, cwt., $3.33, $8.00 Switch Ties #12, 1, set., $186.89, $187.00 Tie Plates, 106, es., $0.29, $31.00 Flanger Signs, 2, ea., $1.60, $3.00 MSE 6%, $78.00 Labor Installation Turnout and Handling, sum, $326.00 Engineering 1%, $18.00 General Expneses 2.3%, $42.00 Salvage: Rail, 2.66, N.T., $45.00, $120.00 OTM, 5.8, N.T., $25.00, $145.00 Labor Removing and Loading Material, sum, $200 Relocating Track, 160, T.F., $2.57, $411.00 Track Ties Replacing Switch Ties: Ties #2 T.S.W. 87, ea., $2.95, $257.00 Labor Inntailing, 87, ea., $1.30, $113.00 Totals: $981, Investment account: $1496, Maintenance account: $611, Other accounts: $265 Ratio used to calculate unit price of OTN - 0.32, See file 4430 - 1 (part 2)" R

Other Names and Numbers

Other Numbers

Number Type

Item Number

Other Number

32817

Dimensions

Height

11 in

Width

8-1/2 in

Parts

Count: none

Location

Location

Box

Canadian National Box #2

Room

Dale Wilson Reference Library

Building

NORMHC Heritage Centre, Northern Ontario Railroad Museum and Heritage Centre

* Untyped Location

Capreol, Ontario

Date

March 10, 2022

Condition

Notes

Fair condition, the one paper is a carbon copy but it is brittle and has a hole in the left hand upper corner
