Note
QST, May 1938, p. 1.
Radio News, May 1938, back cover.
Lafayette catalog number 73, p. 109.
Lafayette catalog number 78, p. 149.
The second in the Sky Buddy series. The other were the 5-T (1935) and the S-19R (1938). A refinement of the 5-T using octal tubes (except for the 80), and a restyled cabinet. Essentially the same basic circuit. No bandspread. The center dial is only a logging scale.A short production run makes the S-19 rare.
Coverage: 550 kHz - 16 MHz
Built-in speaker
IF: 465 kHz
BFO
No bandspread
Power: 120 VAC
Tubes: (1) 6K8, (1) 6L7, (1) 6Q7, (1) 6K6, (1) 80
