Note
Bands : 40 meters, 30 meters and 20 meters
Tuning range: Full band coverage
DDS VFO with 50 Hz slow tuning rate and 200 Hz fast tuning rate
Mode: CW only
Receiver MSD: 0.2 uV typical
Selectivity : 300 Hz
Four crystal IF filter and 600 Hz center frequency audio band pass filter
Receive current, no signal typical:
Active, 47 ma
Idle, 34 ma
Transmitter:
5 watts at 12 volts, all bands +/- 10%
Transmitter current: 650 ma (40M) to 740 ma (20M) typical at 5 watts
Spurs: - 50 dBc maximum, all bands
5 to 40 wpm internal B mode iambic keyer
Two (2) 63 character keyer memories.
Coax or balanced line output
Built in SWR indicator and BLT (balanced line tuner)
Size: 7.2" long, 4.2" wide, 1.5" high (less knob height)
Power supply voltage: 8 volts minimum, 12.5 volts maximum. 12 to 9 volts recommended. External power or internal battery pack
