Basic features include:
Swept Frequency Mode — Fast scan shows VSWR, , match efficiency or return loss across an entire band. A movable cursor can be used to pinpoint a scan frequency and the corresponding measurement value is displayed.
Single Frequency Mode — Provides measurement information in units of Reflection Coefficient (p); Voltage Standing Wave Ratio (VSWR);% Match, or Return Loss (dB) at one frequency on a simulated meter movement. An audio generator can be enabled to produce a tone that is proportional to the match condition.
Auto Scaling — Used in either swept or single frequency modes, sets the Y axis for best measurement display.
Relative Field Strength — Provides means for optimizing the radiated
signal of any transmitter within the specified frequency band.
Limit Testing — Quick pass-fail indication; compares measurements to user selected limits.
Data Storage — Saves and recalls up to 12 traces to be used to set limit or long term monitoring of antenna performance.
Serial Communication Link — Built in serial port and optional software
uploads data to a personal computer for analysis or storage.
