Gonset Communicator II for 6 Meters (#3049, 3049B, 3058, 3058B)

Object/Artifact

-

Radio Alpha

Note that this early production Communicator II is not labeled as a "II," yet can be identified as a "II" by the squelch control and headphone jack. Also note that tuning control knobs were not originally supplied, but were available later as an option. Image: Chuck Penson, WA7ZZE, hamfest.

Note that this early production Communicator II is not labeled as a "II," yet can be identified as a "II" by the squelch control and headphone jack. Also note that tuning control knobs were not originally supplied, but were available later as an option. Image: Chuck Penson, WA7ZZE, hamfest.

Name/Title

Gonset "Communicator II" for 6 Meters (#3049, 3049B, 3058, 3058B)

Description

6 Meter Transceiver

Category

Transceiver, VHF, Kit

Made/Created

Manufacturer

Gonset

Date made

1954 - 1957

Dimensions

Height

9-1/4 in

Width

10-3/8 in

Depth

7-3/4 in

Weight

20 lb

Valuations

Value

$229.50

General Notes

Note

QST, Dec 1954, p. 87. QST, Sep 1955, p. 93. (a few details) QST, Oct 1955, p. 93. (with dimensions) QST, Aug 1956, p. 79 ("B" version) Walter Ashe catalog 1956 (probably issued in 1956), p. 8. (knob kit) The original Communicator II was released in 1953, and covered the 2-meter band. A year later, in December 1954, a Communicator II for 6 meters appeared, as did 12 VDC power supplies. The set weighed 20 lbs., and AM phone power output from the 2E26 final 8–10 watts. Knobs for the tuning controls were not originally supplied, relying instead on screwdriver adjustments. For additional details, see Gonset 3025. Model 3049 (3049B) (for 6 VDC and 120 VAC) Model 3058 (3058B) (for 12 VDC and 120 VAC)
