Specifications
– Input voltage: 120/220/240V AC ± 10%, 50/60 Hz
– Output voltage: 13.8V DC (standard voltage)
– Output current:
20 A (25% duty cycle)
15 A (50% duty cycle)
Continuous load current: 10 A max. (including external output terminal)
– Output voltage fluctuation: Within ± 0.7 V at AC 120V, 220V, 240V ± 10% (Load current: 15 A); Within 0.7 V between 2-15 A load; (No-load output voltage: Less than 16 V at 120/220/240 V AC)
– Ripple voltage: Less than 20 mV (rms) at 13.8 V, output current 15 A.
– Power consumption: Approx. 480 W (at load current DC, 20 A)
Dimensions:
Weight: Approx. 7 kg (15.4 lbs.)
(Note: Circuit design and ratings are subject to change for improvement without notice.)
