Note
Specifications
– Power requirement: 120/220/240 VAC ±10%, 50/60 Hz
– Output current:
20A max. (Continuous operation for 1 hour. Includes external output terminal).
16A max. (External output terminal)
– Output voltage regulation:
±0.7 volts (at 120 VAC, ±10%) with 16 amp load)
±0.7 volts (at load current variations from 2 to 20 amps)
– Ripple voltage: Less than 20 mVrms (at 13.8 VDC, 20 amps)
– Power consumption: Approx. 500W ±10% (at 13.8 VDC, 20 amps)
