Note
QST, Apr 1977, p. 113.
QST, Nov 1977, p. 105.
* Full band coverage 160-10 meters, including MARS.
* 2000 watts PEP SSB input, 1000 watts input continuious duty, CW.
RTTY & SSTV
* Two EIMAC 3-500Z
* All major HV and other components mounted on a single G-10 glass plug-in board.
* Heavy duty commercial grade quaily and construction
Heavy duty 10 KW silver plated ceramic band switches • silver plated copper tubing tank coil • Large 4" meters measure plate current, high voltage, and RF drive, and relative output • Continuous duty power supply • zener diode standby and operating bias provides reduced idling current and greater efficiency • built-in T/R relays • tuned input circuits • ALC rear panel connections for ALC output to exciter and relay control • double internal shielding .
Power: 110 or 220 VAC. 50-60 Hz
