Note
Introduced in 1976 as a matching, direct-companion accessory for the Yaesu FT-301 and FT-301D series HF transceivers, which were famous for being Yaesu's first all-solid-state 100-watt HF rigs. The FC-301 remained in production alongside the FT-301 series until the line was discontinued around the turn of the decade.
Technical Specifications
– Frequency Coverage: 160m (Low and High segments), 80m, 40m, 20m, 15m, and 10m band.
– Input Impedance: 50–75 ohms
– Load Impedance Variation Limits:
With a 50 ohm input: 10 – 250 ohms
With a 75 ohm input: 18 – 300 ohms
– Maximum Transmitter Power: 500 Watts PEP at 50 ohms
– Insertion Loss: 0.5 dB maximum.
– SWR Calibration Range: Up to 4:1 SWR.
