Plane, Combination

Object/Artifact

-

Swedish American Museum

2020.6.10_contents3_object1_side1

2020.6.10_contents3_object1_side1

Name/Title

Plane, Combination

Entry/Object ID

2020.6.10

Description

A combination wood working plane, or also known as the Stanley No. 45, that contains 31 individual pieces (2020.6.10.1-31) which can be assembled together to create a working tool.

Use

Woodworking

Acquisition

Accession

2020.6

Source or Donor

Sharp, Judith

Acquisition Method

Gift

Credit Line

Gift of Judith Sharp

Made/Created

Manufacturer

Stanley Rule and Level Company

Time Period

20th Century

Inscription/Signature/Marks

Type

Makers Mark

Location

Along the blade of the plane, near the bottom left hand corner

Transcription

STANELY RULE 8 CO PAT MC 11 11.84 8A-22.95

Material/Technique

Engraved

Notes

Some of the lettering is hard to decipher due to usage, what is descripted is not entirely completed, but what can be visually seen.

Lexicon

LOC Thesaurus for Graphic Materials

Woodwork, Carpentry, Tools

Dimensions

Dimension Description

Main Stock

Height

5-1/2 in

Width

2-1/2 in

Dimension Description

Sliding Section

Height

2-7/8 in

Width

2 in

Length

10 in

Dimension Description

Fence

Height

3 in

Width

5 in

Length

9 in

Dimension Description

Short Arms

Length

4-1/4 in

Dimension Description

Long Arms

Length

8-1/4 in

Dimension Description

Depth Gauge

Height

1-3/8 in

Width

5/8 in

Length

1-1/2 in

Dimension Description

Slitter Cutter

Width

3/8 in

Length

2-5/8 in

Dimension Description

Wooden Razor Box

Width

3-3/8 in

Depth

1/2 in

Length

10-1/4 in

Dimension Description

Razor Box Lid

Height

1/2 in

Width

3-3/8 in

Length

10-1/4 in

Material

Wood, Metal alloy
