Journal Box Tops - Folio “G”

Drawing

-

The National Museum of Transportation

Full-size 300ppi digital scans of this drawing are available; please email us at museum@tnmot.org for more information.

Full-size 300ppi digital scans of this drawing are available; please email us at [email protected] for more information.

Name/Title

Journal Box Tops - Folio “G”

Entry/Object ID

ACF 21110166 Rev B

Tags

ACF (American Car and Foundry), Digital/Physical

Description

Created by ACF (American Car and Foundry), this technical drawing specifies a cast iron lid for a journal box. It shows various dimensions and sectional views for the casting, and includes a log table tracking orders from 1922 to 1935.

Collection

American Car & Foundry (ACF) Drawing Archive.

Category

Engineering Drawings / Blueprints

Made/Created

Artist

ACF draftsmen

Manufacturer

ACF (American Car and Foundry)

Date made

Sep 12, 1922

Time Period

20th Century

Place

City

Saint Charles

State/Province

Missouri

Country

United States of America

Continent

North America

Location

Category

Permanent

Created By

Mogerman, Jordan

Create Date

July 21, 2026

Updated By

Mogerman, Jordan

Update Date

July 25, 2026
