Patent model of a new system for carriage brakes.
The model is just the chassis and wheels of the carriage, in two pieces. The pieces are held together through a pin that connects the front axle to the body of the chassis.
The whole chassis is made of wood and metal, with four wheels, the front pair smaller than the rear. The braking system is activated when the carriage rolls backward, or by a hand brake that is connected to a lever at the left front of the chassis.
The brakes themselves are in front of the rear carriage wheels, held in place by a strip going horizontally across the width of the chassis. When the lever is activated, the wood strip slides backwards and engages the brakes.Context
Made by Benjamin F. Wheeler of Calais, VT
From a label in an exhibit: "The self-acting brake no longer stopped forward motion, but prevented a wagon from rolling backward when it was ascending a hill."Acquisition
