1988- VTech- Laser 128 (3/2024)Tags
Video TechnologyDescription
1988- The Laser 128 EX is the successor of the Laser 3000. Like the 3000, it is fully compatible with the Apple II computer, but has enhanced features. Video Technology designed its own Apple II compatible ROM (Apple lost a lawsuit challenging it), this ROM holds an Applesoft compatible version of the BASIC. The "Open Apple" and "Closed Apple" keys have been replaced with "Open Triangle" and "Closed Triangle" keys. The 128EX/2's Video Display Generator chip also provided both analog RGB video (for connecting an Apple IIGS, Amiga, or Atari ST monitor) and digital RGB video (for connecting a CGA monitor). In RGB mode, the Video Display Generator (VDG) chip generates a text character set identical to an IBM PC (with the addition of the Open and Closed Triangle characters) The drive and the external daisy-chainable SmartPort floppy drive is driven by Video Technologies custom "Universal Disk Controller" (UDC) disk array chip. The SmartPort supports Apple IIe/IIc UniDisks (3.5" and 5.25" models), Macintosh 3.5" drives (the ones without the buttons), Apple IIGS daisy-chainable 3.5" drives and Apple 5.25" disks. It is also designed to support the Chinook CT-series 20 MB to 100 MB SmartPort hard drives. The SmartPort can support two 800K 3.5" drives, two 140K 5.25" drives, and one 100 MB CT100 hard drive simultaneously daisy-chained to each other.
The Apple bus compatible expansion slot can hold an Apple High Speed (DMA) SCSI controller for running additional SCSI based storage devices.
This unit was so successful that Apple Computers was prompted to upgrade the IIc to counter it. The result was the Apple IIc Plus, also released in 1988. The IIc Plus had a 4 Mhz Western Design Center 65C02 processor, an 800K 3.5" drive built-in, and an External Drive "SmartPort" capable of the same tricks as the Laser's.
Although the two units were similarly matched, Video Technology actively advertised the Laser 128EX/2 while Apple had moved on to promoting the Macintosh.
The Laser became the most successful Apple II clone ever and this model was 99.8% IIc Plus compatible. The only two pieces of software the Apple magazines reported as incompatible were The New Print Shop (Brøderbund Software) and HomeWord (Sierra).
